Model 2651A High Power System SourceMeter® Instrument Reference Manual Section 7: Command reference

2651A-901-01 Rev. A / March 2011 7-163

Usage

code = scriptVar.source

scriptVar.source = nil

scriptVar

The name of the variable that references the script that contains the source code

code

The body of the script

Details

The loadscript or loadandrunscript and endscript keywords are not included in the source code.

The body of the script is a single string with lines separated by the new line character.

The instrument automatically keeps the source for all scripts loaded on the instrument. To free up memory or to

obfuscate the code, assign nil to the source attribute of the script. Although this attribute is writable, it can only

be set to the nil value.

Example

print(test1.source)

Gets source code for a script named test1.

Also see

scriptVar.list() (on page 7-160)

serial.baud

This attribute configures the baud rate for the RS-232 port.

Type TSP-Link accessible Affected by Where saved Default value

Attribute (RW) Yes Not applicable Nonvolatile memory 9600

Usage

baud = serial.baud

serial.baud = baud

baud

The baud rate (300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600 or

115200)

Details

A new baud rate setting takes effect when the command to change it is processed.

NOTE

Allow ample time for the command to be processed before attempting to communicate with the

instrument again. If possible, set the baud rate from one of the other command interfaces or from the

front panel.

The reset function has no effect on data bits.

Example

serial.baud = 1200

Sets the baud rate to 1200.
