Appendix E: Status model Model 2651A High Power System SourceMeter® Instrument Reference Manual
E-4 2651A-901-01 Rev. A / March 2011
Status function summary
Type Function or attribute
*
Questionable status
status.questionable.*
status.questionable.calibration.*
status.questionable.instrument.*
status.questionable.instrument.smua.*
status.questionable.over_temperature.*
status.questionable.unstable_output.*
status.questionable.over_temperature.*
status.questionable.unstable_output.*
Standard event
status.standard.*
System summary
status.system.*
status.system2.*
status.system3.*
status.system4.*
status.system5.*
* = .condition, .event, .ntr, .ptr and .enable;
Status model diagrams
The following figures graphically describe the status model:
• Status model overview (on page E-4)
• Measurement event registers (on page E-5)
• System summary and standard event registers (on page E-6)
• Operation status registers (on page E-7)
• Operation status trigger overrun registers (on page E-8)
• Operation status trigger timer, trigger blender, and remote registers (on page E-9)
• Operation status digital I/O and TSP-Link registers (on page E-10)
• Questionable status registers (on page E-11)
