Section 7: Command reference Model 2651A High Power System SourceMeter® Instrument Reference Manual
7-294 2651A-901-01 Rev. A / March 2011
Usage
operationRegister = status.operation.remote.condition
operationRegister = status.operation.remote.enable
operationRegister = status.operation.remote.event
operationRegister = status.operation.remote.ntr
operationRegister = status.operation.remote.ptr
status.operation.remote.enable = operationRegister
status.operation.remote.ntr = operationRegister
status.operation.remote.ptr = operationRegister
operationRegister
The operation status remote summary register's status. A zero (0) indicates no bits
set (also send 0 to clear all bits); other values indicate various bit settings
Details
These attributes are used to read or write to the operation status remote summary registers. Reading a status
register returns a value. The binary equivalent of the returned value indicates which register bits are set. The
least significant bit of the binary number is Bit B0, and the most significant bit is Bit B15.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register sets
(on page E-
2) and Enable and transition registers
(on page E-18). The individual bits of this register have the following
meanings:
Bit Value Description
B0 Not used Not applicable.
B1
status.operation.remote.COMMAND_AVAILABLE
status.operation.remote.CAV
Set bit indicates there is a command
available in the execution queue.
Bit B1 decimal value: 2
Binary value: 0000 0000 0000 0010
B2-B10 Not used Not applicable.
B11
status.operation.remote.PROMPTS_ENABLED
status.operation.remote.PRMPT
Set bit indicates command prompts are
enabled.
Bit B11 decimal value: 2048
Binary value: 0000 0100 0000 0000
B12-B15 Not used Not applicable.
As an example, to set bit B1of the operation status remote summary enable register, set
status.operation.remote.enable = status.operation.remote.CAV.
In addition to the above constants, operationRegister can be set to the numeric equivalent of the bit to set.
To set more than one bit of the register, set operationRegister to the sum of their decimal weights. For
example, to set bits B1 and B11, set operationRegister to 2050 (which is the sum of 2 + 2048).
Example
status.operation.remote.enable =
status.operation.remote.CAV
Sets the CAV bit of the operation status
remote summary enable register using a
constant.
Also see
Operation Status Registers (on page E-20)
status.operation.*
(on page 7-266)
