430 Keysight N9010A EXA Service Guide
Replaceable Parts
Hardware
Figure 14-14 RF Area - Option 532, 544 with Option B40, MPB, or DP2 (switch detail)
Item Description Keysight Part Number
1SW4 Transfer Switch, 50 GHz (Options B40, MPB, or DP2) 87222-60031
W10 Cable Assembly, J1 to A9 Input (Semi Rigid) N9020-20133
W31 Cable Assembly, SW2 Center Port to A11J3 (Semi-rigid) E4410-20161
W32 Cable Assembly, SW2 Port 2 to A12J2 (Semi-rigid) E4410-20163
W33 Cable Assembly, SW1 Port 2 to A12J1 (Semi-rigid) E4410-20165
W34 Cable Assembly, SW1 Center Port to A13J9 (Semi-rigid) E4410-20164
W35 Cable Assembly, AT1 to SW1 Port 1 (Semi-rigid) E4410-20178
