Keysight Technologies X Series Service Guide

Keysight N9010A EXA Service Guide 433
Replaceable Parts
Hardware
Figure 14-16 Front End Parts - Option 532, 544
Item Description Keysight Part Number
1 A13 RF Front End Assembly Refer to Table 14-1
2 A13A1 Bandpass Filter Refer to Table 14-1
A13W1 Cable Assembly, A13J10 to A13A1 Input (Semi Rigid) Refer to Table 14-1
A13W2 Cable Assembly, A13J11 from A13A1 Output (Semi Rigid) Refer to Table 14-1
3 A12 YTF Preselector 5087-7383
4 J1 2.4 m Input Connector Assembly (Option 532, 544) N9030-60011
5 A11 Low Band Switch Assembly N9020-60051
W3 Cable Assembly, A11J2 to A13J2 (Semi Rigid) N9020-20131
W4 Cable Assembly, A14J740 to A13J4 (Semi Rigid) N9020-20156
