438 Keysight N9010A EXA Service Guide
Replaceable Parts
Hardware
Item Description Keysight Part Number
1A15 Front End Control Assembly Refer to Table 14-1
2 A14 L.O. Synthesizer Assembly Refer to Table 14-1
W4 Cable Assembly, A14J740 to A13J4 (Semi Rigid) N9020-20156
W6 Cable Assembly, A16J703 to A14J200 (Semi Rigid)
Serial number < MY/SG/US56480000 N9020-20154
Serial number ≥ MY/SG/US56480000 N9020-20033
W16 Cable Assembly, A9 & A10 to A15J801 or A15J102 (Ribbon
Cable)
E4410-60157
W17 Cable Assembly, A13 to A15J104 (Ribbon Cable) E4410-60156
W18 Cable Assembly, A11J4 to A15J103 or A15J700 (Ribbon Cable)
Option 503, 507, 513, 526 E4410-60160
Option 532, 544 N9020-60092
W22 Cable Assembly, A15J301 or A15J300 to A12J1 (Wire Harness) Refer to Table 14-1
