237
Global edit mode
MIDI: MIDI In Control
Reference
Local Control On
The Local parameter turns the keyboard on or off.
Note: The Local parameter is automatically reactivated each time
you turn the instrument on.
On When you play the keyboard, MIDI data is sent to
the internal sound generator. If tracks are
assigned to a MIDI OUT channel, data is also
sent to the MIDI OUT port.
Off The keyboard is connected to the MIDI OUT, but
cannot play the internal sound generator.
This is very useful when working with an external
sequencer, to send notes and various MIDI mes-
sages from the integrated keyboard and control-
lers to the external sequencer, and then let the
sequencer send them back to the sound genera-
tor, without overlapping. See the MIDI chapter.
MIDI A Out/Thru Mode
MIDI B Out/Thru Mode
Use these radio buttons to define if the MIDI OUT connector
must work as OUT or THRU connectors. (OUT ports send data
generated by the Pa1X, while THRU connectors send the same
data received on the MIDI IN port).
MIDI: MIDI In Control
This page lets you program general parameters for the MIDI IN,
like the Chord Recognition channel and MIDI parameters for
the Voice Processor.
Midi In Controls
Midi In Octave Transpose
Use this parameter to determine if the Octave Transpose is
applied also to notes received on the MIDI IN.
On Notes received on the MIDI IN are transposed
according to the Octave Transpose setting for
each track.
Off Data received on the MIDI IN are not transposed.
Midi In Mute/Unmute
Use this parameter to determine if a muted track can still play
data received via MIDI.
On No data received via MIDI on a muted track can
be played by Pa1X.
Off Data received via MIDI on a muted track can still
play on the Pa1X.
Chord 1 Midi Channel
Chord 2 Midi Channel
Notes entering these channels are sent to the Chord Recognition
engine.
There are two separate Chord channels. This is very useful when
you must send chords to Pa1X on two different channels (like
with some MIDI accordions).
Upper Octave Transp (Transpose)
Octave transposition of data received on the MIDI IN for the
Upper tracks. For example, if you select the +1 value, a received
C4 will play a C5 on the Pa1X.
This parameter may be useful to many MIDI accordion players,
whose MIDI interface may transmit on an unexpected octave.
Lower Octave Transp (Transpose)
Octave transposition of data received on the MIDI IN for the
Lower track. For example, if you select the +1 value, a received
C4 will play a C5 on the Pa1X.
This parameter may be useful to many MIDI accordion players,
whose MIDI interface may transmit on an unexpected octave.
Midi In Velocity Value
Use this parameter to set a fixed velocity (dynamics) value for all
received MIDI notes. This is useful when playing the Pa1X with
an organ or a MIDI Accordion.
Normal Normal velocity values are received.
40…127 All received velocity values are converted to the
selected value.
Voice Processor Midi controls
Midi In Channel
Notes received on this channel are sent to the Harmony section
of the Voice Processor.
Octave Transpose In
Octave transpose for all notes received via MIDI by the Har-
mony section of the Voice Processor.
In Note Range-High
In Note Range-Low
These parameters are the lowest and highest notes received by
the Harmony section of the Voice Processor. Notes received out
of this range are not recognized.
Mid
Mid
Mid
Mid
Mid
Mid
Mid
Mid
Mid
Mid
Mid
Mid
Mid
