330
Filter/Dynamic
Filter and dynamics control effects
000: No Effect
Select this option when you do not use any effects. When this
option is selected, the effect is muted.
001: Amp. Simulation
This effect simulates the frequency response characteristics of
guitar amplifiers. It is also effective for organ and drum sounds.
002: Compressor
This effect compresses the input signal to regulate the level and
give a “punchy” effect. It is useful for guitar, piano, and drum
sounds. This is a stereo compressor. You can link left and right
channels, or use each channel separately.
a: Envelope Select
This parameter selects whether the left and right channels are
linked to control both signals simultaneously, or whether each
channel is controlled independently.
b: Sensitivity, f: Output Level
The “Sensitivity” parameter sets the sensitivity of the compressor.
If this parameter is set to a higher value, lower level sounds will
be boosted. With a higher Sensitivity, the overall volume level is
higher. To adjust the final volume level, use the “Output Level”
parameter.
a
Amplifier Type
Selects the type of guitar amplifier
Solid State, British
(EL84), American
(6L6)
b
Wet/Dry Dry, 1:99...99:1, Wet
Sets the balance between the effect and dry sounds
Src Off...Tempo
Selects the modulation source of the effect balance
Amt
Sets the modulation amount of the effect balance
–100...+100
Left
Right
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Amp Simulation Filter
Amp Simulation Filter
a
Envelope Select L/R Mix, L/R Individually
Determines whether the left and right channels are linked or used separately
☞
b
Sensitivity
Sets the sensitivity
1...100
☞
c
Attack
Sets the attack level
1...100
☞
d
EQ Trim
Sets the EQ input level
0...100
e
Pre LEQ Gain [dB]
Sets the gain of Low EQ
–15.0...+15.0dB
Pre HEQ Gain [dB]
Sets the gain of High EQ
–15.0...+15.0dB
f
Output Level
Sets the output level of the compressor
0...100
☞,
Src Off...Tempo
Selects the modulation source for the compressor output level
Amt –100...+100
Sets the modulation amount of the compressor output level
g
Wet/Dry Dry, 1:99...99:1, Wet
Table , “Sets the balance between the effect and dry sounds,” on page 330
Src Off...Tempo
Table , “Selects the modulation source of the effect balance,” on page 330
Amt
Table , “Sets the modulation amount of the effect bal-
ance,” on page 330
–100...+100
Left
Right
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
EQ Trim
EQ Trim
LEQ HEQ
LEQ
HEQ
Compressor
Compressor
Envelope Select
Output Level
Output Level
Envelope - Control
Envelope - Control
Sensitivity=100
Sensitivity=40
Dry
Wet
Time
Level
Compressor - Sensitivity
Louder
