Korg PA1X User Manual

146
Song Play operating mode
STS Name panel
choose the internal or the external display as the one that must
be perfectly lined.
Int. Video When pressing the control corresponding to the
Text Down command, the first line of the current
page of text is shown on top of the internal video.
The external video might not be perfectly lined.
Choose this option if you are reading verses from
the internal display.
Ext. Video When pressing the control corresponding to the
Text Down command, the first line of the current
page of text is shown on top of the external video.
The internal video might not be perfectly lined.
Choose this option is your audience is reading
verses from an external video.
Note: When this option is selected, the text scrollbar
disappears from the internal display.
Text files loaded with Standard MIDI Files
and MP3 files
When a “.TXT” file exists in the same directory as a Standard
MIDI File or MP3 file, and shares exactly the same name, it will
be loaded with the “.MID” or “MP3” file, and can be seen in the
Lyrics page.
As an example, if the file “MYSONG.TXT” exists in the same
directory as the “MYSONG.MID” or “MYSONG.MP3” file, it is
loaded together with the matching “.MID” or “.MP3” file.
However, unlike ordinary Lyrics, the text will not scroll automat-
ically while the Song is playing back. You must scroll it with the
DIAL. As an alternative, you can use an assignable switch or
footswitch, with the Text Page Up or Text Page Down functions
assigned, to scroll (respectively) to the previous or next text
page.
Note: When a “.TXT” file is loaded with the Song, it overrides any
included Lyrics data.
STS Name panel
Select this panel to see the name of the four available STSs. See
“STS Name panel” on page 82 for details.
Mic panel
Select this panel to set parameters for the microphone input. See
“Mic panel” on page 82 for details.
Sub-Scale panel
Select this panel to select a secondary scale for the Keyboard
tracks. See “Mixer/Tuning: Sub Scale” on page 86 for details.
Pad panel
Select this panel to see which Hit or Sequence Pads are assigned
to the four Pads. See “Pad panel” on page 83 for details.
Split panel
Select this panel to adjust the split point for the Keyboard tracks.
See “Split panel” on page 83 for details.

Korg PA1X Specifications

General

Polyphony	62 voices
Sound Engine	HI synthesis (Hyper Integrated)
Display	TouchView graphical touch screen
Sequencer	16-track sequencer
Storage	floppy disk drive
Connectivity	MIDI In/Out/Thru, USB
Outputs	Headphones
Inputs	Microphone Input
