282
MIDI
Connecting the Pa1X to a MIDI accordion
section in the control panel will affect the notes received from
the master keyboard.
Connections and settings
To connect the master keyboard to the Pa1X follow this proce-
dure:
1. Connect the MIDI OUT connector of the master keyboard
to one of the MIDI IN connectors of the Pa1X (IN A sug-
gested).
2. Program the master keyboard to transmit over the Global
channel of the Pa1X (see “MIDI: MIDI In Channels” on
page 238).
For information on the master keyboard programming, see
the master keyboard own user’s manual.
3. Select the MIDI Setup parameter. You can do this by going
to the “MIDI: MIDI Setup / General Controls” page of the
Global mode, or in the dedicated page of the Style Play,
Song Play or Sequencer mode (see “Midi Setup” on
page 96, “Midi Setup” on page 153, and “Midi Setup” on
page 186).
Note: A different MIDI Setup may be selected for the Style
Play, Song Play and Sequencer modes. The “1-Default” MIDI
Setup is automatically selected when entering the Sound Edit
mode. MIDI settings are therefore modified when switching to
a different operating mode. The current MIDI Setup is also
shown in the Global mode.
4. Select the “Master Keyboard” MIDI Setup.
Note: Settings may change when new Global data is loaded
from disk. To protect settings from loading, use the Global
Protect function (see “Global Protect” on page 272).
5. To save the assigned MIDI Setup for the selected operative
mode into the Global, select the “Write Global-Style
Setup”, the “Write Global-Song Play Setup”, the “Write
Global-Seq. Setup”, or the “Write Global-Global Setup”
command from the page menu.
6. If needed, press one of the buttons in the MODE section to
go to the desired operative mode.
Connecting the Pa1X to a MIDI accordion
There are various types of MIDI accordions, each one requiring
different MIDI settings. Pa1X is provided with a series of “Accor-
dion” MIDI Setups, each one suitable for a different MIDI accor-
dion (see page 236).
Connection and settings
To connect the accordion to the Pa1X follow this procedure:
1. Connect the MIDI OUT connector of the accordion to one
of the MIDI IN connectors of the Pa1X (IN A suggested).
2. Select the MIDI Setup parameter. You can do this by going
to the “MIDI: MIDI Setup / General Controls” page of the
Global mode, or in the dedicated page of the Style Play,
Song Play or Sequencer mode (see “Midi Setup” on page 96
and “Midi Setup” on page 153).
Note: A different MIDI Setup may be selected for the Style
Play, Song Play and Sequencer modes. The “1-Default” MIDI
Setup is automatically selected when entering the Sound Edit
mode. MIDI settings are therefore modified when switching to
a different operating mode. The current MIDI Setup is also
shown in the Global mode.
3. Select one of the available “Accordion” MIDI Setups.
Note: Settings may change when new Global data is loaded
from disk. To protect settings from loading, use the Global
Protect function (see “Global Protect” on page 272).
4. To save the assigned MIDI Setup for the selected operative
mode into the Global, select the “Write Global-Style
Setup”, the “Write Global-Song Play Setup”, the “Write
Global-Seq. Setup”, or the “Write Global-Global Setup”
command from the page menu.
5. If needed, press one of the buttons in the MODE section to
go to the desired operative mode.
