Pa1X is equipped with four powerful Effect Processors. You can
send them the internal tracks, or any signal entering the Audio
Inputs.
Diagrams
The following instructions show the signal path diagram for
each of the effect types. The signal coming from the tracks
(Send) is mono. Before entering an effect processor, it is split in
two “wires” (Left and Right), and processed in stereo. The signal
is then output in stereo from the effect processor, and sent to the
Mix output (Left&Right, the heaphones or the internal speak-
ers).
Dynamic Modulation sources
When the symbol is encoutered, a Dynamic Modulation
can be applied to the corresponding parameter. The following
table shows the available modulation sources.
Some notes on the Gate parameters follow.
Gate1, Gate1+Dmpr (Gate1+Damper)
The effect is at maximum during note-on, and will stop when all
keys are released. With Gate1 + Dmpr, the effect will remain at
maximum even after the keys are released, as long as the damper
(sustain) pedal is pressed.
Gate2, Gate2+Dmpr (Gate2+Damper)
This is essentially the same as for Gate 1 or Gate 1 + Dmpr.
However when Gate 2 or Gate 2 + Dmpr are used as a dynamic
modulation source for the EG of 022: St. Envelope Flanger etc.
or the AUTOFADE of 027: Stereo Vibrato, a trigger will occur at
each note-on. (In the case of Gate 1 and Gate 1 + Dmpr, the trig-
ger occurs only for the first note-on.)
Effects
Modulation source Note
Off No modulation
Gate1
Gate1+Dmpr
Gate2
Gate2+Dmpr
Note Nr Note Number
Velocity Note Velocity
AfterTouch After Touch
JS X Joystick Left/Right
JS+Y: CC#01 Joystick Forward
JS-Y: CC#02 Joystick Backward
MIDI(CC#04)
MIDI(CC#12)
MIDI(CC#13)
MIDI(CC#16)
MIDI(CC#18)
MIDI(CC#17)
MIDI(CC#19)
MIDI(CC#20)
MIDI(CC#21)
Damper: #64
Prta.SW: #65 Portamento Switch
Effect Block
Diagram
Send
Left
Right
Sostenu: #66 Sostenuto Pedal
MIDI(CC#80)
MIDI(CC#81)
MIDI(CC#82)
MIDI(CC#83)
Tempo
Modulation source Note
Gate1,Gate1+Dmpr
Gate1
Note
Dmpr
1
2
3
1
2
3
DamperPedal
Gate1+Dmpr
Time
On
Off
Gate2,Gate2+Dmpr
Gate2
Note
Dmpr
1
2
3
1
2
3
Damper Pedal
Gate2+Dmpr
Time
On
Off
