241
Global edit mode
Audio Output: Metro / S/PDIF
Reference
In 2
The line input In 2 may be routed to the Right output, or deacti-
vated, depending on the status of the SELECT switch on the rear
panel.
• If the SELECT switch it is set to “MIC”, this input is sent to
the Right output.
• If the SELECT switch is set to “1”, it is deactivated.
Voice Processor Out
Use this parameter to assign an audio output (OUTPUT section,
on the back of the instrument) to the Voice Processor.
In 1/2 Out
Non editable. These output are fixed, and cannot be changed.
Audio Output: Metro / S/PDIF
This page lets you define various parameters for the Metronome,
the S/PDIF output, and the Speakers (for the Pa1X with inte-
grated speakers).
Metronome
Mode
Use this parameter to activate the metronome for the Style Play
and/or Song play operating modes.
Off No metronome is heard.
Style The metronome is always activated when playing
a Style.
Song The metronome is always activated when playing
a Song.
Style+Song The metronome is always activated when playing
a Style or Song.
Volume
Use this parameter to set the volume of the metronome.
Click Out
The metronome’s click can be routed to any audio output.
Hint: When sending the click to your drum player, we suggest to
select one of the sub-outs Out 1 and 2, to avoid it is sent to the audi-
ence through the Left+Right outputs.
Note: The selected Metronome Mode must not be Off, in order for
the click to be sent to an audio output during playback.
See “Tracks” on page 239 for detailed information on the avail-
able outputs.
S/PDIF Out
S/PDIF On/Off
Use this parameter to turn the S/PDIF digital audio output on or
off.
Note: This parameter is automatically set to Off each time you turn
the instrument on.
On All tracks set to be sent to the Left+Right audio
outputs (see from page 239) are sent to the S/
PDIF output. Together with the audio signal, the
Word Clock sync signal is also output, with a fre-
quency of 48kHz.
When in this mode, the Pa1X becomes the Word
Clock master. No other master device can be con-
nected to the same digital audio system. Please,
refer to the connected audio device (mixer, audio
card…) for information on how to set it as a
Word Clock slave.
Off No signal is sent to the S/PDIF output.
Speakers
Speakers On/Off
Not available on the Pa1X Pro. On a Pa1X with integrated speak-
ers, use this checkbox to turn speakers on or off. This option is
useful when the instrument is connected to an external amplifi-
cation system, and you don’t need the speakers.
Audio Output: MP3/CD
In this page you can program the MP3 (EXBP-MP3) and Audio
CD (CDRW-1) options.
MP3 Board
This section only appears when the optional EXBP-MP3 board has
been installed.
