Korg PA1X User Manual

300
Factory data
Drum Kit maps
Drum Kit maps
Legend: In the following Drum Kit tables, the number 120-x-x before each Drum Kit’s name represents the Bank Select MSB (CC00) - Bank
Select LSB (CC32) - Program Change (PC) combo. The Sample columns contain each sample’s number and name. Excl is the Exlcusive
parameter: when a note is struck, all other notes with the same Exclusive number assigned are stopped. A number between round parenteses
(n) means a velocity switch, and the number of used velocity layers.
120-0-0: Standard Kit RX1 120-0-1: Standard Kit RX2 120-0-2: Standard Kit RX3 120-0-3: Acoustic Kit
Note Sample Excl. Sample Excl. Sample Excl. Sample Excl.
0 C-1 45 SD Wood 2 pp Off 45 SD Wood 2 pp Off 45 SD Wood 2 pp Off 45 SD Wood 2 pp Off
1 C#-1 60 SD Solid2 p Off 60 SD Solid2 p Off 60 SD Solid2 p Off 60 SD Solid2 p Off
2 D-1 79 SD Brass2 mf Off 79 SD Brass2 mf Off 79 SD Brass2 mf Off 79 SD Brass2 mf Off
3 D#-1 75 SD Brass1 p Off 75 SD Brass1 p Off 75 SD Brass1 p Off 75 SD Brass1 p Off
4 E-1 69 SD Maple2 pp Off 69 SD Maple2 pp Off 69 SD Maple2 pp Off 69 SD Maple2 pp Off
5 F-1 63 SD Maple1 pp Off 63 SD Maple1 pp Off 63 SD Maple1 pp Off 63 SD Maple1 pp Off
6 F#-1 57 SD Solid1 p Off 57 SD Solid1 p Off 57 SD Solid1 p Off 57 SD Solid1 p Off
7 G-1 53 SD Piccolo2 pp Off 53 SD Piccolo2 pp Off 53 SD Piccolo2 pp Off 53 SD Piccolo2 pp Off
8 G#-1 5 BD Dry 1 Off 5 BD Dry 1 Off 5 BD Dry 1 Off 5 BD Dry 1 Off
9 A-1 25 BD House 4 Off 25 BD House 4 Off 25 BD House 4 Off 25 BD House 4 Off
10 A#-1 228 99 SD Off 228 99 SD Off 228 99 SD Off 228 99 SD Off
11 B-1 40 BD Deep 88 Off 40 BD Deep 88 Off 40 BD Deep 88 Off 226 88 BD Off
12 C0 227 88 SD Off 227 88 SD Off 227 88 SD Off 227 88 SD Off
13 C#0 53~56 SD Piccolo2 pp~f (4) Off 69~74 SD Maple2 pp~ff (6) Off 45~48 SD Wood 2 pp~f (4) Off 89 SD Off Center Off
14 D0 49~52 SD Piccolo1 pp~f (4) Off 63~68 SD Maple1 pp~ff (6) Off 42~44 SD Wood 1 p~f (3) Off 100 SD Cracker Room Off
15 D#0 10 BD Jazz (2) Off 10 BD Jazz (2) Off 10 BD Jazz (2) Off 11 BD Pillow Off
16 E0 7 BD Dry 3 Off 1 BD Acoust.1 mf Off 1 BD Acoust.1 mf Off 38 BD Amb.Rocker Off
17 F0 57~59 SD Solid1 p~f (3) Off 49~52 SD Piccolo1 pp~f (4) Off 63~68 SD Maple1 pp~ff (6) Off 91 SD Amb.Piccolo Off
18 F#0
160~165 HH2 Closed pp~ff (6) Off 152~155 HH1 Closed pp~f (4) Off 152~155 HH1 Closed pp~f (4) Off 171 HH3 Closed2 1
19 G0 8 BD Normal Off 4 BD Acoust.2 f Off 4 BD Acoust.2 f Off 10 BD Jazz Off
20 G#0 129 Rim Shot f Off 129 Rim Shot f Off 129 Rim Shot f Off 130 Side Stick Dry Off
21 A0 45~48 SD Wood 2 pp~f (4) Off 60~62 SD Solid2 p~f (3) Off 53~56 SD Piccolo2 pp~f (4) Off 220 SD Orchestra 7
22 A#0 42~44 SD Wood 1 p~f (3) Off 57~59 SD Solid1 p~f (3) Off 49~52 SD Piccolo1 pp~f (4) Off 219 SD Orch. Roll 7
23 B0 132 Drum Stick Hit Off 132 Drum Stick Hit Off 132 Drum Stick Hit Off 132 Drum Stick Hit Off
24 C1 78~80 SD Brass2 p~f (3) Off 78~80 SD Brass2 p~f (3) Off 78~80 SD Brass2 p~f (3) Off 220 SD Orchestra 7
25 C#1 81 SD Roll 7 81 SD Roll 7 81 SD Roll 7 219 SD Orch. Roll 7
26 D1 221 Finger Snaps Off 221 Finger Snaps Off 221 Finger Snaps Off 221 Finger Snaps Off
27 D#1 270 Zap2 Off 270 Zap2 Off 270 Zap2 Off 270 Zap2 Off
28 E1 410 Noise White Off 410 Noise White Off 410 Noise White Off 410 Noise White Off
29 F1 272 DJ Scratch2 7 272 DJ Scratch2 7 272 DJ Scratch2 7 272 DJ Scratch2 7
30 F#1 272 DJ Scratch2 7 272 DJ Scratch2 7 272 DJ Scratch2 7 272 DJ Scratch2 7
31 G1 132 Drum Stick Hit Off 132 Drum Stick Hit Off 132 Drum Stick Hit Off 132 Drum Stick Hit Off
32 G#1 269 Zap1 Off 269 Zap1 Off 269 Zap1 Off 269 Zap1 Off
33 A1 376 Click Off 376 Click Off 376 Click Off 376 Click Off
34 A#1 340 Triangle Open Off 340 Triangle Open Off 340 Triangle Open Off 340 Triangle Open Off
35 B1 3~4 BD Acoust.2 mf~f (3) Off 0~2 BD Acoust.1 p~f (4) Off 0~2 BD Acoust.1 p~f (4) Off 8 BD Normal Off
36 C2 0~2 BD Acoust.1 P~f (4) Off 3~4 BD Acoust.2 mf~f (3) Off 3~4 BD Acoust.2 mf~f (3) Off 11-5 BD Pillow-Dry 1 (2) Off
37 C#2 128-129 Rim Shot p-f (2) Off 128-129 Rim Shot p-f (2) Off 128 Rim Shot p-f (2) Off 131 Side Stick Amb Off
38 D2 69~74 SD Maple2 pp~ff (6) Off 45~48 SD Wood 2 pp~f (4) Off 60~62 SD Solid2 p~f (3) Off 86-87 SD Ghost p-f (2) Off
39 D#2 230 88 Claps Off 230 88 Claps Off 230 88 Claps Off 225 Claps 4 Off
40 E2 63~68 SD Maple1 pp~ff (6) Off 42~44 SD Wood 1 p~f (3) Off 57~59 SD Solid1 p~f (3) Off 86-87 SD Ghost p-f (2) Off
41 F2 139-140 Tom1 Floor p-f (2) Off 139-140 Tom1 Floor p-f (2) Off 139-140 Tom1 Floor p-f (2) Off 145 Tom3 Floor Off
42 F#2
160~165 HH2 Closed pp~ff (6) 1 152~155 HH1 Closed pp~f (4) 1 152~155 HH1 Closed pp~f (4) 1 174 HH3 Open 2 1
43 G2 137-138 Tom1 Low p-F (2) Off 137-138 Tom1 Low p-f (2) Off 137-138 Tom1 Low p-f (2) Off 145 Tom3 Floor Off
44 G#2
166-167 HH2 Foot p-F (2) 1 156-157 HH1 Foot mp-mf (2) 1 156-157 HH1 Foot mp-mf (2) 1 178 HH4 Foot 1
45 A2 135-136 Tom1 Mid p-F (2) Off 135-136 Tom1 Mid p-f (2) Off 135-136 Tom1 Mid p-f (2) Off 144 Tom3 Low Off
46 A#2
168-169 HH2 Open p-f (2) 1 158-159 HH1 Open mp-mf (2) 1 158-159 HH1 Open mp-mf (2) 1 173 HH3 Open 1 1
47 B2 135-136 Tom1 Mid p-f (2) Off 135-136 Tom1 Mid p-f (2) Off 135-136 Tom1 Mid p-f (2) Off 144 Tom3 Low Off
48 C3
133-134 Tom1 Hi p-f (2) Off 133-134 Tom1 Hi p-f (2) Off 133-134 Tom1 Hi p-f (2) Off 143 Tom3 Hi Off
49 C#3 195 Crash 19'open2 (2) Off 193 Crash 17'edge2 (2) Off 193 Crash 17'edge2 (2) Off 196 Crash 1 Off
50 D3
133-134 Tom1 Hi p-f (2) Off 133-134 Tom1 Hi p-f (2) Off 133-134 Tom1 Hi p-f (2) Off 143 Tom3 Hi Off
51 D#3 207-209 Ride 20' mp2-mf2 (2) Off 207-209 Ride 20' mp2-mf2 (2) Off 207 Ride 20' mp2 Off 213 Ride Edge 2 Off
52 E3 198 China Off 198 China Off 198 China Off 198 China Off
53 F3 215 Ride Cup Off 215 Ride Cup Off 215 Ride Cup Off 215 Ride Cup Off
54 F#3 339 Tambourine Acc2 Off 339 Tambourine Acc2 Off 339 Tambourine Acc2 Off 339 Tambourine Acc2 Off
55 G3 199 Splash 8'edge1 Off 199 Splash 8'edge1 Off 199 Splash 8'edge1 Off 201 Splash Off
56 G#3 352 Cowbell Off 352 Cowbell Off 352 Cowbell Off 352 Cowbell Off
57 A3 193 Crash 17'edge2 (2) Off 191 Crash 15'edge2 (2) Off 191 Crash 15'edge2 (2) Off 196 Crash 1 Off
58 A#3 325 Vibraslap Off 325 Vibraslap Off 325 Vibraslap Off 325 Vibraslap Off
59 B3 206-208 Ride 20' mp1-mf1 (2) Off 206-208 Ride 20' mp1-mf1 (2) Off 208 Ride 20' mf1 Off 214 Ride Jazz Off
60 C4 298 Bongo Hi Open Off 298 Bongo Hi Open Off 298 Bongo Hi Open Off 298 Bongo Hi Open Off
61 C#4 295 Bongo Lo Open Off 295 Bongo Lo Open Off 295 Bongo Lo Open Off 295 Bongo Lo Open Off
62 D4 292 Conga Hi Slap2 Off 286 Conga Lo Mt Slap Off 286 Conga Lo Mt Slap Off 290 Conga Hi Mt Slap Off
63 D#4 288 Conga Hi Open Off 288 Conga Hi Open Off 288 Conga Hi Open Off 288 Conga Hi Open Off
64 E4 285 Conga Lo Open Off 285 Conga Lo Open Off 285 Conga Lo Open Off 285 Conga Lo Open Off
65 F4 334 Timbale Hi Rim2 Off 334 Timbale Hi Rim2 Off 334 Timbale Hi Rim2 Off 334 Timbale Hi Rim2 Off
66 F#4 329 Timbale Lo Open Off 329 Timbale Lo Open Off 329 Timbale Lo Open Off 329 Timbale Lo Open Off
67 G4 351 Agogo Bell Off 351 Agogo Bell Off 351 Agogo Bell Off 351 Agogo Bell Off
68 G#4 351 Agogo Bell Off 351 Agogo Bell Off 351 Agogo Bell Off 351 Agogo Bell Off
69 A4 346 Cabasa Up Off 346 Cabasa Up Off 346 Cabasa Up Off 346 Cabasa Up Off
70 A#4 309 Maracas Push Off 309 Maracas Push Off 309 Maracas Push Off 309 Maracas Push Off
71 B4 361 Samba Whistle 2 361 Samba Whistle 2 361 Samba Whistle 2 361 Samba Whistle 2

Korg PA1X Specifications

General

Polyphony	62 voices
Sound Engine	HI synthesis (Hyper Integrated)
Display	TouchView graphical touch screen
Sequencer	16-track sequencer
Storage	floppy disk drive
Connectivity	MIDI In/Out/Thru, USB
Outputs	Headphones
Inputs	Microphone Input
