Korg PA1X User Manual

396
Installing the hard disk (Pa1X only)
Formatting the hard disk
When the installation is finished, reconnect the power cable and
turn the instrument on. You must format the hard disk before it
can be used.
1. Press DISK to access the Disk edit mode.
2. Select the “Format” page.
3. Use the Device selector to select the hard disk (“HD”).
4. Press the (Text Edit) button in the display to assign a
label (name) to the hard disk.
5. Select the Full Format option, then press the Execute but-
ton, and follow the instructions that appear in the display.
Device selector

Korg PA1X Specifications

General

Polyphony	62 voices
Sound Engine	HI synthesis (Hyper Integrated)
Display	TouchView graphical touch screen
Sequencer	16-track sequencer
Storage	floppy disk drive
Connectivity	MIDI In/Out/Thru, USB
Outputs	Headphones
Inputs	Microphone Input
