179
Sequencer operating mode
Mixer/Tuning: Volume/Pan
Reference
Mixer/Tuning: Volume/Pan
This page lets you set the volume and pan for each Song track.
Use the TRK. SEL. button to switch between Song tracks 1-8 and
9-16.
Pan
Track position in the stereo field.
L-64…L-1 Left stereo channel.
C 00 Center.
R+1…R+63 Right stereo channel.
Off If the track’s output status is Left&Right (normal
setting), the direct (uneffected) signal is not sent
to the outputs; only the FX signal is heard for this
track.
If the track is sent to a separate output, no FX is
sent to any output.
To program the output status for each track, see
“Audio Output: Sty/Kbd” on page 239.
Volume
Track’s volume.
0…127 MIDI value of the track’s volume.
Play/Mute icon
Track’s play/mute status.
Play status. The track can be heard.
Mute status. The track cannot be heard.
Mixer/Tuning: FX Send
This page lets you set the level of the track’s direct (uneffected)
signal going to the Internal FX processors. The effect processors
included in Pa1X are connected in parallel, so you can decide
which percentage of the direct signal can be effected:
In case you do not want to send a track’s direct signal to the out-
put, but only the effected signal (as when using “insert” effects,
like Rotary, Distortion, EQ…), just set the Pan to Off (see “Pan”
above):
There are four Internal FX processors in Sequencer mode,
grouped in two pairs (AB and CD). Usually you will create Songs
with only a pair (preferably AB), but you can create Songs using
both FX pairs. We suggest to use A and C as reverb processors,
and B and D as modulating effect processors.
Use the TRK. SEL. button to switch between Song tracks 1-8 and
9-16, and vice-versa.
FX Groups
Use this pop-up menu to select one of the two FX groups (AB or
CD).
Send level
0…127 Level of the track (direct) signal sent to the effect
processor.
Track Out L/R
FX Processor
Track Out L/R
FX Processor
