MIDI Data
MIDI Controllers
Appendix
MIDI Controllers
The following is a table including all Control Change messages,
and their effect on various Pa1X functions.
(*) The following NRPN messages are recognized by the Pa1X:
Note: These controls are reset when stopping the Song, or choosing
a new Song.
MIDI Data
CC# CC Name Pa1X Function
0 Bank Select Program selection
1 Mod1 (Y+) Joystick forward
2 Mod2 (Y-) Joystick backward
3 Undef. ctl
4 Foot ctl
5 Port.time
6 Data ent.
7 Volume Track volume
8 Balance
9 Undef. ctl
10 Pan Pot Track panning
11 Expression Expression
12 Fx Ctl 1
13 Fx Ctl 2
14-15 Undef. ctl
16 Gen.pc.1
17 Gen.pc.2
18 Slider
19 Gen.pc.4
20-31 Undef. ctl
Control Change #32-63 are the LSB (Least Significant Bytet) of Con-
trol Change #0-31, i.e. the MSB (Most Significant Byte), and are
changed according to their MSB counterparts.
64 Damper Damper pedal
65 Portamento
66 Sostenuto Sostenuto pedal
67 Soft pedal Soft pedal
68 Legato
69 Hold 2
70 Sustin level
71 F.Res.Hp Filter resonance
72 Release Release time
73 Attack Attack time
74 F.CutOff Filter cutoff (Brilliance)
75 Decay T. Decay time
76 Lfo1 Sp. Vibrato speed
77 Lfo1 Dpt Vibrato depth
78 Lfo1 Dly Vibrato initial delay
79 FilterEg
80 Gen.pc.5
81 Gen.pc.6
82 Gen.pc.7
83 Gen.pc.8
84 Port.ctl
85-90 Undef. ctl
91 Fx A/C A/C (reverb) send level
92 Fx 2 ctl
93 Fx B/D B/D (modul.) send level
94 Fx 4 ctl
95 Fx 5 ctl
96 Data Inc
97 Data Dec
98 NRPN Lsb
See table below
(*)
99 NRPN Msb*
See table below
(*)
100 RPN Lsb
101 RPN Msb
102-119 Undefined ctl
120 AllSOff
121 Res Ctl Reset All Controllers
122 LocalCt
123 NoteOff
124 OmniOff
125 Omni On
126 Mono On
127 Poly On
NRPN
CC#99
(MSB)
CC#98
(LSB)
CC#06
(Data Entry)
Vibrato Rate 1 8
0…127
(a)
(a). 64 = No change to the original parameter’s value
Vibrato Depth 1 9
0…127
(a)
Vibrato Decay 1 10
0…127
(a)
Filter Cutoff 1 32
0…127
(a)
Resonance 1 33
0…127
(a)
EG Attack Time 1 99
0…127
(a)
EG Decay Time 1 100
0…127
(a)
EG Release Time 1 102
0…127
(a)
Drum Filter Cutoff 20
dd
(b)
(b). dd = Drum Instrument No. 0…127 (C0…C8)
0…127
(a)
Drum Filter Resonance 21
dd
(b)
0…127
(a)
Drum EG Attack Time 22
dd
(b)
0…127
(a)
Drum EG Decay Time 23
dd
(b)
0…127
(a)
Drum Coarse Tune 24
dd
(b)
0…127
(a)
Drum Fine Tune 25
dd
(b)
0…127
(a)
Drum Volume 26
dd
(b)
0…127
Drum Panpot 28
dd
(b)
0…127
(a)
Drum Rev Send (FX 1) 29
dd
(b)
0…127
(a)
Drum Mod Send (FX 2) 30
dd
(b)
0…127
(a)
CC# CC Name Pa1X Function
