MIDI Data
MIDI Implementation Chart
Appendix
MIDI Implementation Chart
Function Transmitted Recognized Remarks
Basic Channel
Default 1–16 1–16 Memorized
Changed 1–16 1–16
Mode
Default 3
Messages X X
Altered ****************
Note
Number:
0–127 0–127
True Voice **************** 0–127
Velocity
Note On O 9n, V=1–127 O 9n, V=1–127
Note Off X V=64 X
Aftertouch
Poly (Key) O O Sequencer data only *A
Mono (Channel) O O *A
Pitch Bend
OO
Control
Change
0, 32 O O Bank Select (MSB, LSB) *A
1, 2 O O Modulations *A
6 O O Data Entry MSB *A
38 X O Data Entry LSB *A
7, 11 O O Volume, Expression *A
10, 91, 93 O O Panpot, A/C FX Send, B/D FX Send *A
64, 66, 67 O O Damper, Sostenuto, Soft *A
65, 5 O O Portamento On/Off, Portamento Time *A
71, 72, 73 O O Harmonic Content, EG time (Release, Attack) *A
74, 75 O O Brightness, Decay Time *A
76, 77, 78 O O Vibrato Rate, Depth, Delay *A
98, 99 O O NRPN (LSB, MSB) *A, 1
100, 101 O O RPN (LSB, MSB) *A, 2
120, 121 X O All sounds off, Reset all controllers *A
Program
Change
O 0–127 O 0–127 *A
True # **************** 0–127
System Exclusive
XX *3
System
Common
Song Position X X
Song Select X X
Tune X X
System
Real Time
Clock O O *4
Commands O O *4
Aux
Messages
Local On/Off X X
All Notes Off X O (123–127)
Active Sense O O
Reset X X
Notes
*A: Sent and received when MIDI Filters In and Out are set to Off in Global mode.
*1: Drawbars settings, Sound parameters, Selection of SongBook entries.
*2: LSB, MSB = 00,00: Pitch Bend range, =01,00: Fine Tune, =02,00: Course Tune.
*3: Includes Inquiry and Master Volume messages, FX settings, Quarter Tone settings.
*4: Transmitted only when the Clock Send parameter (Global mode) is set to on.
Mode 1:OMNI ON, POLY
Mode 3:OMNI OFF, POLY
Mode 2:OMNI ON, MONO
Mode 4:OMNI OFF, MONO
O: Yes
X: No
KORG Pa1X
OS Version 2.5 - May. 15, 2005
