Leica FlexLine plus - Starting and Configuring Traverse

FlexLine plus, Programs
115
7.14.2 Starting and Configuring Traverse
Access

It is not recommended to start a traverse if the memory is almost full. Doing so, may
mean the traverse measurements and results cannot be saved. Accordingly, a message
is displayed if less than 10% of the memory is free.
Traverse
configuration
Next step
Press Cont to confirm the traverse configuration and proceed to the Enter Station
Data screen.
Measure Traverse -
Enter Station Data

Every Traverse must start on a known point.
Next step Press Cont to confirm station data and proceed to the Traverse - Select screen.
1. Select Programs from the Main Menu.
2. Select Traverse from the Programs Menu.
3. Complete program pre-settings.
• F1 Set Job:
Only one traverse per job is allowed. If an adjusted or finished traverse is
already part of the selected job, then select another job. Refer to "6 Programs
- Getting Started".
• F2 Set Tolerances:
Use Tolerances: Yes to activate the use of tolerances.
Enter limits for horizontal direction (the difference between measured and
calculated azimuth to the closing point), distance (the distance between
known and measured closing point), and for differences in Easting, Northing
and Height. If the adjustment results, or the deviation for a check point, exceed
these limits a warning message appears.
Press Cont to save the limits and return to the Pre-settings screen.
4. Select F4 Start to begin the program.
Field Description
Traverse ID Name of the new traverse.
Desc. Description, if desired.
Operator Name of the user who will be using the new traverse, if desired.
Method B'F'F"B" All points are measured in face I, then all points are meas-
ured in face II in reverse sequential order.
B'B"F"F' The backsight point is measured in face I immediately
followed by face II. Other points are measured in alter-
nating face order.
B'F' All points are measured in face I only.
No. of Sets Number of sets. Limited to 10.
Use Face-Tol. Important when measuring with face I and II. This checks if both meas-
urements are within a defined limit. If the limit is exceeded, a warning
message is displayed.
Face-Tol. The limit that will be used for checking the face tolerance.
Field Description
Stat.ID Name of the station.
hi Height of the instrument.
Desc. Description of the station, if desired.
