FlexLine plus, MapView Interactive Display Feature
133
10 MapView Interactive Display Feature
10.1 Overview
Availability
Description MapView is an interactive display feature embedded in the firmware. MapView
provides a graphical display of the survey elements which allows for a better overall
understanding of how the data being used and measured relates to each other.
Depending on the application and where in the application MapView is accessed from,
different functionality is available.
The displayed data in all modes of MapView can be shifted by using both the arrow
keys and the touchscreen.
10.2 Accessing MapView
Description The MapView interactive display feature is provided as a page within applications. It is
accessed through the application itself. Depending on the application and from where
in the application MapView is accessed, different MapView modes are available.
Access To view points on a map:
•In Q-Survey/Survey change to page 4/4 for Black&White display and to page Map
for Color&Touch display.
To select points from a map - for programs where points can be selected from
the database:
• For TS09 plus: Press Map in the screen where points must be selected. Use the
touch screen to select points.
• For TS06 plus: Point selection is not possible on the map.
10.3 Configuring MapView
Access
Access from the
MapView toolbar
For C&T: Tap on the MapView toolbar.
TS02 plus - TS06 plus TS09 plus
1. Select Settings from the Main Menu.
2.
Select Screen… from the Settings Menu.
3.
Press to scroll through the screens of available settings.
