Leica FlexLine plus - 2 System Description

FlexLine plus, Description of the System
22
2 Description of the System
2.1 System Components
Main components
a) FlexLine plus instrument
with FlexField plus firmware
b) Computer with Instrument
Tools software
c) Data transfer
Component Description
FlexLine plus
instrument
An instrument for measuring, calculating and capturing data. Ideally
suited for tasks from simple surveys to complex applications.
Equipped with a FlexField plus firmware package to complete these
tasks.
The various lines have a range of accuracy classes and support
different features. All lines can be connected with Instrument Tools
to view, exchange and manage data.
Two different telescopes are available. The symbols used in this
manual are:
Ergofocus (Type 3)
Finefocus (Type 2)
FlexField plus
firmware
The firmware package installed on the instrument. Consists of a
standard base operating system with optional additional features.
Instrument
Tools software
An office software consisting of a suite of standard and extended
programs for the viewing, exchanging, managing and post
processing of data.
Data transfer Data can be always transferred between a FlexLine plus instrument
and a computer via a data transfer cable.
For instruments equipped with a Communication side cover data can
also be transferred via USB memory stick, USB cable, or Bluetooth.
TSOX_001
a
c
b
Flex
Office
