6.4 Station Setup
Description All measurements and coordinate computations are referenced to the set station
coordinates and orientation.
Station coordinate calculation
Station orientation calculation
Access Select F2 Station Setup in Config. screen.
Next step
The Station Setup program begins. Refer to "7.2 Station Setup" for information on the
Station Setup process.

If no station was set and a program was started, then the last station is set as the
current station and the current horizontal direction is set as the orientation.
Directions
XEasting
YNorthing
ZHeight
Station coordinates
X0 Easting coordinate of station
Y0 Northing coordinate of station
Z0 Height of station
P0 Instrument station
Known coordinates
P1 Target point
P2 Target point
P3 Target point
Calculations
Hz1 Station orientation
TSOX_097
ZY
Y
0
X0
Z0
X
TSOX_025
P1
P2
Hz1
Hz=0
P0
P3
