FlexLine plus, Technical Data
173
17.6 General Technical Data of the Instrument
Telescope
Compensation Quadruple axis compensation (2-axis compensator with Hz-collimation and V-Index).
Level
Control unit
Instrument Ports
* Only for instruments fitted with a Communication side cover.
Magnification: 30 x
Free Objective aperture: 40 mm
Focusing: 1.7 m/5.6 ft to infinity
Field of view: 1°30’/1.66 gon.
2.7 m at 100 m
Angular accuracy Setting accuracy Setting range
["] ["] [mgon] [’] [gon]
10.50.2±40.07
20.50.2±40.07
310.3±40.07
51.50.5±40.07
720.7±40.07
Circular level sensitivity: 6’/2 mm
Electronic level resolution: 2"
B&W display: 288 x 160 pixels, LCD, backlit, 8 lines with 31 characters each,
heatable (temp. <-5°).
C&T display: 320 x 240 pixels (QVGA), LCD, backlit, 9 lines with 31 characters
each, keyboard illumination
Name Description
RS232 5 pin LEMO-0 for power, communication, data transfer.
This port is located at the base of the instrument.
USB host port* USB memory stick port for data transfer.
USB device port* Cable connections from USB devices for communication and data
transfer.
Bluetooth* Bluetooth connections for communication and data transfer.
