Leica FlexLine plus - 5 Instrument Settings; 5.1 Work Settings Configuration

FlexLine plus, Settings
41
5 Settings
5.1 Work Settings
Access
Work Settings
1.
Select Settings from the Main Menu.
2. Select Work from the Settings Menu.
Field Description
Trigger Key1
Trigger Key2
Trigger Key 1 is the top end of the trigger key. Trigger Key 2 is the
lower end of the trigger key.
Off The trigger key is deactivated.
Meas Sets the trigger key with the same function as Meas.
Dist Sets the trigger key with the same function as Dist.
USER Key 1
USER Key 2
Configures or with a function from the Favourites menu. Refer
to "8 Favourites".
Tilt Correct Off Tilting compensation deactivated.
On 2-axis compensation. Vertical angles refer to the
plummet line and the horizontal directions are
corrected by the standing axis tilt.
For corrections depending on the Hz Corr. setting,
refer to the table "Tilt and horizontal corrections".

If the instrument is used on an unstable base, for example a shaking
platform or ship, the compensator should be deactivated. This avoids
the compensator drifting out of its measuring range and interrupting
the measuring process by indicating an error.
Hz Corr. On Horizontal corrections are activated. For normal
operation the horizontal correction should remain
active. Each measured horizontal angle will be
corrected, depending on the vertical angle.
For corrections depending on the Tilt Correct
setting, refer to the table "Tilt and horizontal correc-
tions".
Off Horizontal corrections are deactivated.
Line1 Fixed to Point ID Shown on a page in Quick Survey and Survey.
Line2 to
Line14
The settings define the parameters shown on a page in Quick Survey
and Survey.
Target Height Input field for prism height.
Code Editable field for codes.
Hz angle Display only field for the horizontal angle.
V angle Display only field for vertical angle.
Hor. dist. Display only field for horizontal distance.
Slope dist. Display only field for measured slope distance.
Height diff. Display only field for the height difference between
station and reflector.
Easting Display only field for Easting coordinate of meas-
ured point.
Northing Display only field for Northing coordinate of meas-
ured point.
