FlexLine plus, Technical Data
169
17.3 Distance Measurement without Reflectors (Non-Prism mode)
Range Power Pinpoint R500 (without reflector)
Ultra Pinpoint R1000 (without reflector)
Atmospheric
conditions
Accuracy Valid for and .
Beam interruptions, severe heat shimmer and moving objects within the beam path
can result in deviations of the specified accuracy.
* Accuracy and measure time depend on atmospheric conditions, target object and
observation situation.
Characteristics
Laser dot size
Kodak Gray Card Range D Range E Range F
[m] [ft] [m] [ft] [m] [ft]
White side, 90 % reflective 250 820 400 1312 >500 >1640
Grey side, 18 % reflective 100 330 150 490 >250 >820
Kodak Gray Card Range D Range E Range F
[m] [ft] [m] [ft] [m] [ft]
White side, 90 % reflective 800 2630 1000 3280 >1000 >3280
Grey side, 18 % reflective 400 1320 500 1640 >500 >1640
Range of Measurement: 1.5 m to 1200 m
Display unambiguous: up to 1200 m
Range D: Object in strong sunlight, severe heat shimmer
Range E: Object in shade, or overcast
Range F: Underground, night and twilight
Standard
measuring
ISO 17123-4 Measure time,
typical [s]
Measure time,
maximum [s]
0 m - 500 m 2 mm + 2 ppm 3 - 6 15
>500 m 4 mm + 2 ppm 3 - 6 15
Tracking measuring* Standard deviation Measure time, typical [s]
Tracking 5mm + 3ppm
0.25
1.00
Type: Coaxial, visible red laser
Carrier wave: 658 nm
Measuring system:
System analyser basis 100 MHz - 150 MHz
Distance measurement system using phase-shift prin-
ciple with frequency 320 MHz
Distance [m] Laser dot size, approximately [mm]
at 30 7 x 10
at 50 8 x 20
at 100 16 x 25
