Leica FlexLine plus - Data Settings

FlexLine plus, Settings
46
5.3 Data Settings
Access
Data Settings
1. Select Settings from the Main Menu.
2.
Select Data from the Settings Menu.
3.
Press to scroll through the screens of available settings.
Field Description
Double PtID Sets if multiple points are able to be recorded with the same point ID
in the same job.
Allowed Allows multiple points with the same point ID.
Not Allowed Does not allow multiple points with the same point
ID.
Sort Type Time Lists are sorted by time of entry.
PtID Lists are sorted by Point IDs.
Sort Order Descending Lists are ordered in descending order of sort type.
Ascending Lists are ordered in ascending order of sort type.
Code Record Sets if the codeblock is saved before or after the measurement. Refer
to "9 Coding".
Code Sets if the code will be used for one, or many, measurements.
Reset after Rec The set code is cleared from the measurement
screen after Meas or Store is selected.
Permanent The set code remains in the measurement screen
until manually deleted.
Data Output Sets the location for data storage.
Internal
Memory
All data is recorded in the internal memory.
Interface Data is recorded via the serial interface, the USB
device port or Bluetooth, depending on the port
selected in the Interface Settings screen. This Data
Output setting is only required if an external storage
device is connected and measurements are started
at the instrument with Dist/Store or Meas. This
setting is not required if the instrument is totally
controlled by a datalogger.
GSI-Format Sets the GSI output format.
GSI 8 81..00+12345678
GSI 16 81..00+1234567890123456
GSI-Mask Sets the GSI output mask.
Mask 1 PtID, Hz, V, SD, ppm+mm, hr, hi.
Mask 2 PtID, Hz, V, SD, E, N, H, hr.
Mask 3 StationID, E, N, H, hi (Station).
StationID, Ori, E, N, H, hi (Station Result).
PtID, E, N, H (Control).
PtID, Hz, V (Set Azimuth).
PtID, Hz, V, SD, ppm+mm, hr, E, N, H (Measure-
ment).
