Leica FlexLine plus - Check Tie

FlexLine plus, Favourites
127
8.4 Check Tie
Description This favourite calculates and displays the slope and horizontal distance, height differ-
ence, azimuth, grade, and coordinate differences between the last two measured
points. Valid distance measurements are required for the calculation.
Access
Check Tie
Messages The following are important messages or warnings that may appear.
aAzimuth
Slope distance
Height distance
Horizontal distance
P0 Instrument station
P1 First point
P2 Second point
TSOX_021
P0
P1
P2
a
1. Press the FNC/Favourites key when within any program.
2. Select CheckTie from the Favourites Menu.
Field Description
Bearing Difference in bearing between the two points.
Grade Difference in gradient between the two points.
Difference in horizontal distance between the two points.
Difference in slope distance between the two points.
 Difference in height between the two points.
Messages Description
Two measurements
required!
The values cannot be calculated as there are less than two
valid measurements.
