Leica FlexLine plus - 3.4 Softkey Functionality

FlexLine plus, User Interface
30
3.4 Softkeys
Description Softkeys are selected using the relevant F1 to F4 function key. This chapter describes
the functionality of the common softkeys used by the system. The more specialised
softkeys are described where they appear in the program chapters.
Common softkey
functions
Key Description
Cont If entry screen: Confirms measured or entered values and continues the
process.
If message screen: Confirms message and continues with selected action
or returns to the previous screen to reselect an option.
Back To return to the last active screen.
Default To reset all editable fields to their default values.
Dist To start distance and angle measurements without saving the measured
values.
EDM To view and change EDM settings. Refer to "5.5 EDM Settings".
ENH To open the manual coordinate entry screen.
Find To search for an entered point.
Input TS02 plus: To activate alphanumerical softkeys for text entry.
List To display the list of available points.
Meas To start distance and angle measurements and save the measured values.
Quit To exit the screen or program.
Store To save the displayed values.
View To display the coordinate and job details of the selected point.
-> ABC To change the keypad operation to alphanumerical.
-> 345 To change the keypad operation to numerical.
To display the next softkey level.
To return to the first softkey level.
