7.14.4 Moving ahead
Number of defined
sets is achieved
When the number of defined sets is achieved, the Traverse - Select screen is
displayed automatically. The accuracy of the set measurements is checked. The set can
be accepted or redone.
Moving ahead with
the traverse
From the Traverse - Select screen, select an option to move ahead with the traverse,
or press ESC to redo the last station.
Next step
Close the traverse by selecting Close in the Sight Foresight! screen after a backsight
point measurement, but before the foresight point measurement.
Field Description
F1 Survey Side-
shot
Enables the measurement of standard survey and topographic
points. Measured points are stored with a Traverse flag. If the
traverse is finally adjusted, these points will be updated.
Close
To exit the Measure Sideshot! screen and returns to the Trav-
erse - Select screen.
F2 Move to next
Station
Move to the next station. The instrument can either be left on or
turned off. If the instrument is turned off and then turned on
again later, the message Last traverse not yet finished or
processed! Do you really want to start a new traverse ? All
existing data will be overwritten! will display. Selecting Yes will
re-open the Traverse to continue at the new station.
The start screen for the next station is similar to the Enter Station
Data screen. The point ID of the foresight point of the last station
is suggested as station ID automatically.
Run through the loop of backsight and foresight measurements
until the number of sets is reached.
F3 Measure
Checkpoint
By measuring a check point it is possible to check whether the
Traverse is still within certain deviations. A check point is excluded
from the traverse calculation and adjustment, however, all meas-
urement data and results observed from a check point are stored.
1) Enter the name of the check point and the height of the
reflector.
2) Press Cont to go to the next screen.
3) Measure the check point. The differences in Easting,
Northing and Height are displayed.
A message will appear if the tolerances defined in the Traverse
configuration are exceeded.
