Leica FlexLine plus - 12 Instrument Tools; 12.1 Instrument Adjustment

FlexLine plus, Tools
139
12 Tools
12.1 Adjust
Description The Adjustments Menu contains tools to be used for the electronic adjustment of the
instrument and for setting adjustment reminders. Using these tools helps to maintain
the measuring accuracy of the instrument.
Access
Adjustment options In the Adjustments screen, there are several adjustment options.
1.
Select Tools from the Main Menu.
2. Select Adjust from the Tools Menu.
3. Select an Adjustment option from the Adjustments screen.
Menu selection Description
Hz-Collimation Refer to "14.3 Adjusting Line-of-Sight and Vertical Index Error".
Vertical Index Refer to "14.3 Adjusting Line-of-Sight and Vertical Index Error".
Compensator
Index
Refer to "14.4 Adjusting the Compensator".
Tilting Axis Refer to "14.5 Adjusting the Tilting Axis Error".
View Current
Adj. Data
Displays the current adjustment values that have been set for Hz-
Collimation, V-index and Tilt Axis.
Set Adjustment
Reminder
Defines the time period from the last adjustment to when a
reminder message should display to do another adjustment.
Options are: Never, 2 weeks, 1 month, 3 months, 6 months,
12months.
The message will display the next time the instrument is switched
on after the time period has been reached.
