FlexLine plus, Data Management
150
13.3 Importing Data
Description For instruments fitted with a Communication side cover, data can be imported to the
internal memory of the instrument via a USB memory stick.
Importable data
formats
When importing data, the instrument automatically stores the file in a directory folder
based on the file extension. The following data formats can be imported:
Access 1) Select Transfer from the Main Menu.
2) Select Import.
Import
• Importing a backup folder will overwrite the existing configuration file and code lists
on the instrument, and all existing formats and jobs will be deleted.
• A backup can only be imported if the instrument database structure was not
changed by a firmware update. If the instrument firmware was updated, it can
happen that a backup created before the update cannot be imported. In this case,
downgrade the firmware to the previous used version, save the data in the way
required and then reload the new firmware.
Data Type File extension Recognised as
GSI .gsi, .gsi (road) Fixpoints
DXF .dxf Fixpoints
LandXML .xml Fixpoints
ASCII any ASCII file extension e.g. .txt Fixpoints
Format .frt Format file
Codelist .cls Codelist file
Configuration .cfg Configuration file
Backup .db Backup of fixpoints, measure-
ments and configuration
Field Description
From USB-Stick
To Instrument
File Import a single file or a backup folder.
To Next Page
