Leica FlexLine plus - Servicing the Tripod

FlexLine plus, Check & Adjust
162
14.8 Servicing the Tripod
Service the tripod
step-by-step
1) Tighten the leg cap screws moderately with the allen key supplied.
2) Tighten the articulated joints on the tripod head just enough to keep the tripod legs
open when lifting the tripod off the ground.
3) Tighten the screws of the tripod legs.

The connections between metal and timber components must always be
firm and tight.
TSOX_122
1
2
3
