Leica FlexLine plus - Page 174

FlexLine plus, Technical Data
174
Instrument
dimensions
Instrument
dimensions
Weight
Tilting axis height
Recording
Laser plummet
TSOX_086
196 mm
316 mm
196 mm
316 mm
225 mm
101.9 mm
101.9 mm
203.8 mm
002726_002
196 mm
316 mm
225 mm
196 mm
316 mm
86.6 mm
86.6 mm
173.2 mm
196 mm
316 mm
225 mm
196 mm
316 mm
86.6 mm
86.6 mm
173.2 mm
Instrument: 4.2 kg - 4.5 kg (depending on hardware configuration)
Tribrach: 760 g
Battery GEB212: 110 g
Battery GEB221: 210 g
Battery GEB222: 210 g
Without tribrach: 196 mm
With tribrach (GDF111): 240 mm ±5 mm
Model Memory Type Capacity [MB] Number of
measurements
TS02 plus Internal memory 32 13,500
TS06 plus / TS09 plus Internal memory 32 60,000
Type: Visible red laser class 2
Location: In standing axis of instrument
Accuracy: Deviation from plumb line:
1.5 mm (2 sigma) at 1.5 m instrument height
Diameter of laser point: 2.5 mm at 1.5 m instrument height
