FlexLine plus, Programs
120
Traverse Results
Next step
Press Adjust from the Traverse Results screen to calculate the adjustments.
Set Adjustment
Parameter
Adjust
To calculate an adjustment. Unavail-
able when the traverse is left open.
ViewTol
To view the tolerances for the trav-
erse.
S-Shot
To measure a sideshot.
EndTrav
To record the results and end the trav-
erse.
Field Description
Traverse ID Name of the traverse.
Start Stn. Point ID of the start station.
End Stn. Point ID of the end station.
No.of Stn. Number of stations in the traverse.
Total Dist. Total distance of the traverse.
1D Accuracy Accuracy in 1D Length of Traverse
Height Misclosure
2D Accuracy Accuracy in 2D Length of Traverse
Linear Misclosure
L of Error Length/distance error.
Azimuth Err. Azimuth closure error.
∆East, ∆North, ∆Height Calculated coordinates.
1/ ( )
1/ ( )
Field Description
No.of Stn. Number of stations in the traverse.
Azimuth Err. Azimuth closure error.
Misc.-Distr. For misclosure distribution.

Angle misclosures are distributed equally.
Compass For surveys where angles and distances were meas-
ured with equal precision.
Transit For surveys where angles were measured with a
higher precision than the distances.
Height-Distr The height error can be distributed equally, by distance or not at all.
