FlexLine plus, Settings
54
Leica standard
settings
When Default is selected the communication parameters are reset to the default Leica
standard settings:
• 115200 Baud, 8 Databit, No Parity, CR/LF Endmark, 1 Stopbit.
Interface plug
connections
a) External battery
b) Not connected / inactive
c) GND
d) Data reception (TH_RXD)
e) Data transfer (TH_TXD)
TSOX_029
a
b
c
d
e
