148
the blank field.
4. Click the save to save the setting
5. If you want to cancel the setting then you need to click the Reset button. It will
revert to previously saved values
Figure 2-12.1.3: The IGMP Snooping Port Group Filtering Profile.
Parameter description:
Port :
The logical port for the settings.
Filtering Profile :
Select the IPMC Profile as the filtering condition for the specific port. Summary
about the designated profile will be shown by clicking the view button.
Profile Management Button :
You can inspect the rules of the designated profile by using the following button:
: List the rules associated with the designated profile.
Buttons:
Apply – Click to save changes.
Reset- Click to undo any changes made locally and revert to previously saved
values.
