LevelOne IGP-1271 - Mirror Port Configuration

271
Parameter description:
 Port to mirror on :
Port to mirror also known as the mirror port. Frames from ports that have either
source (rx) or destination (tx) mirroring enabled are mirrored on this port. Disabled
disables mirroring.
Mirror Port Configuration
The following table is used for Rx and Tx enabling.
 Port :
The logical port for the settings contained in the same row.
 Mode :
Select mirror mode.
Rx only Frames received on this port are mirrored on the mirror port. Frames
transmitted are not mirrored.
Tx only Frames transmitted on this port are mirrored on the mirror port. Frames
received are not mirrored.
Disabled neither frames transmitted nor frames received are mirrored.
Enabled Frames received and frames transmitted are mirrored on the mirror port.
NOTE: For a given port, a frame is only transmitted once. It is
therefore not possible to mirror Tx frames on the mirror port.
Because of this, mode for the selected mirror port is limited to
Disabled or Rx only.
 Buttons:
Apply – Click to save changes.
