3-6.2.3 ACL Status
The section describes how to shows the ACL status by different ACL users. Each row
describes the ACE that is defined. It is a conflict if a specific ACE is not applied to the
hardware due to hardware limitations. The maximum number of ACEs is 512 on each
switch.
Web Interface
To display the ACL status in the web interface:
1. Click Monitor, Network, and then ACL status
2. If you want to auto-refresh the information then you need to evoke the
“Auto-refresh”.
3. Click “Refresh“ to refresh the ACL Status
Figure 3-6.2.3: The ACL Rate Limiter Configuration
Parameter description:
User :
Indicates the ACL user.
Ingress Port :
Indicates the ingress port of the ACE. Possible values are:
