The "Start from VLAN", and "group" input fields allow the user to select the starting
point in the IGMP SFM Information Table. Clicking the button will update the
displayed table starting from that or the closest next IGMP SFM Information Table
match. In addition, the two input fields will - upon a button click - assume the value of
the first displayed entry, allowing for continuous refresh with the same start address.
The will use the last entry of the currently displayed table as a basis for the next lookup.
When the end is reached the text "No more entries" is shown in the displayed table.
Use the button to start over.
IGMP SFM Information Table Columns
VLAN ID :
VLAN ID of the group.
Group :
Group address of the group displayed.
Port :
Switch port number.
Mode :
Indicates the filtering mode maintained per (VLAN ID, port number, Group Address)
basis. It can be either Include or Exclude.
Source Address :
IP Address of the source. Currently, system limits the total number of IP source
addresses for filtering to be 128.
Type :
Indicates the Type. It can be either Allow or Deny.
Hardware Filter/Switch
Indicates whether data plane destined to the specific group address from the
source IPv4 address could be handled by chip or not.
Buttons
To Next Page
