87
Buttons
Apply – Click to save changes.
Reset - Click to undo any changes made locally and revert to previously saved
values.
2-5.2.3.3 Access Control List
The section describes how to configure Access Control List rule. An Access Control List
(ACL) is a sequential list of permit or deny conditions that apply to IP addresses, MAC
addresses, or other more specific criteria. This switch tests ingress packets against the
conditions in an ACL one by one. A packet will be accepted as soon as it matches a
permit rule, or dropped as soon as it matches a deny rule. If no rules match, the frame
is accepted. Other actions can also be invoked when a matching packet is found,
including rate limiting, copying matching packets to another port or to the system log,
or shutting down a port.
This page shows the Access Control List (ACL), which is made up of the ACEs defined
on this switch. Each row describes the ACE that is defined. The maximum number of
ACEs is 256 on each switch. Click on the lowest plus sign to add a new ACE to the list.
The reserved ACEs used for internal protocol, cannot be edited or deleted, the order
sequence cannot be changed the priority is highest
Web Interface
To configure Access Control List in the web interface:
1. Click Configuration, ACL, then Configuration
2. Click the button to add a new ACL, or use the other ACL
modification buttons to specify the editing action (i.e., edit, delete, or
moving the relative position of entry in the list)
3. To specific the parameter of the ACE
4. Click the save to save the setting
5. If you want to cancel the setting then you need to click the reset button.
It will revert to previously saved values.
6. When editing an entry on the ACE Configuration page, note that the
Items displayed depend on various selections, such as Frame Type and IP Protocol
Type. Specify the relevant criteria to be matched for this rule,
and set the actions to take when a rule is matched (such as Rate Limiter,
