5.7.2 Monitoring Items
Mode
Code
Function Display
Setting Range
Initial Value
CNF
20
Anytime Para
0
Frequency
0: Frequency
21
Monitor Line-1
1
Speed
0: Frequency
22
Monitor Line-2
2
Output Current
2:Output Current
23
Monitor Line-3
3
Output Voltage
3:Output Voltage
4
Output Power
5
WHour Counter
6
DCLink Voltage
7
DI Status
8
DO Status
9
V1 Monitor [V]
10
V1 Monitor [%]
11
I1 Monitor [mA]
12
I1 Monitor [%]
13
V2 Monitor [V]
14
V2 Monitor [%]
15
I2 Monitor [mA]
16
I2 Monitor [%]
17
PID Output
18
PID Ref Value
19
PID Fdb Value
20
Torque
21
Torque Limit
22
Trq Bias Ref
23
Speed Limit
24
Load Speed
25
Temperature
