LSIS SV-IS7 User Manual

Technical Specifications
8
2.2 Input and Output Specifications 200 V Class (30–
75 kW)
Model SV xxx iS7–2x
0300
0370
0450
0550
0750
Applied
Motor
Normal load
HP
50
60
75
100
120
kW
37
45
55
75
90
Heavy load
HP
40
50
60
75
100
kW
30
37
45
55
75
Rated
output
Rated Capacity (kVA)
46
57
69
84
116
Rated
Current
(A)
Normal
load
146
180
220
288
345
Heavy
load
116
146
180
220
288
Output Frequency
0–400 Hz (Sensorless-1: 0–300 Hz, Sensorless-2, Vector: 0.1–120
Hz)
Output Voltage (V)
3-Phase 200–230 V
Rated
input
Working Voltage (V)
3-Phase 200–230 VAC (-15%–+10%)
Input Frequency
50–60 Hz (5%)
Rated
Current
(A)
Normal
load
152
190
231
302
362
Heavy
load
121
154
191
233
305
• The standard motor capacity is based on a standard 4-pole motor.
• The standard used for 200 V inverters is based on a 200 V supply voltage.
• The rated output current is limited based on the carrier frequency set at CON-04.
• The output frequency is limited to 0–300 Hz if DRV-09 (control mode) is set to “3
(Sensorless-1),” and to 0–120 Hz if DRV-09 (control mode) is set to “4 (Sensorless-3).”
• The maximum output voltage cannot exceed the input voltage of the power source.
