Only use Class H or RK5 UL listed input fuses and UL listed breakers. See the table above for the
voltage and current ratings for the fuses and breakers.
Utiliser UNIQUEMENT des fusibles d’entrée homologués de Classe H ou RK5 UL et des disjoncteurs
UL. Se reporter au tableau ci-dessus pour la tension et le courant nominal des fusibless et des
disjoncteurs.
4.8
Control Terminal Wiring for iS7 Inverters Rated
for Up To 22 kW
The iS7 inverter supports both PNP (Source) and NPN (Sink) modes for sequence inputs at the
terminal. Select an appropriate mode to suit your requirements using the PNP/NPN selection
switch above the control terminal block. Refer to the following information for detailed
applications.
To Next Page
