LSIS SV-IS7 User Manual

Installing the Inverter
Installing
the Inverter
39
3.5 Frame Dimensions and Weight (UL Enclosed Type
1, IP 21 Type)
Inverter
Capacity
W[mm]
H[mm]
D[mm]
Weight[Kg]
w/ built-in
EMC and DCR
Weight[Kg]
w/ built-in
EMC
Weight[Kg]
w/ built-in
DCR
Weight[Kg]
non-DCR
types
SV0008iS7-2/4
150
284
200
5.5
4.5
5.0
4.5
SV0015iS7-2/4
150
284
200
5.5
4.5
5.0
4.5
SV0022iS7-2/4
150
284
200
5.5
4.5
5.0
4.5
SV0037iS7-2/4
150
284
200
5.5
4.5
5.0
4.5
SV0055iS7-2/4
200
355
225
10
8.4
9.3
7.7
SV0075iS7-2/4
200
355
225
10
8.4
9.3
7.7
SV0110iS7-2/4
250
385
284
20
17.2
16.8
14
SV0150iS7-2/4
250
385
284
20
17.2
16.8
14
SV0185iS7-2
280
461.6
298
30
27
25.9
22.9
SV0220iS7-2
280
461.6
298
30
25.8
25.9
22.9
SV0185iS7-4
280
461.6
298
27.4
23.5
23.3
19.7
SV0220iS7-4
280
461.6
298
27.4
23.5
23.5
20.1
SV0300iS7-2
300
570
265.2
-
-
-
29.5
SV0370iS7-2
370
630
281.2
-
-
-
44
SV0450iS7-2
370
630
281.2
-
-
-
44
SV0550iS7-2
465
750
355.6
-
-
-
72.5
SV0750iS7-2
465
750
355.6
-
-
-
72.5
Note
• The weight specified in the table indicates the total weight of the product without packaging,
which includes the built-in parts, such as the EMC filter and DCR.
• The built-in EMC filter and DCR are not available for 30–75 kW (200 V) products.
