LSIS SV-IS7 - Frame Dimensions and Weight (UL Enclosed Type 12, IP54 Type)

Installing the Inverter
Installing
the Inverter
41
3.6 Frame Dimensions and Weight (UL Enclosed Type
12, IP54 Type)
Inverter
Capacity
W[mm]
H[mm]
D[mm]
Weight[Kg]
w/ built-in
EMC and DCR
Weight[Kg]
w/ built-in
EMC
Weight[Kg]
w/ built-in
DCR
Weight[Kg]
non-DCR
types
SV0008iS7-2/4
204
419
208
8.2
7.2
7.7
6.7
SV0015iS7-2/4
204
419
208
8.2
7.2
7.7
6.7
SV0022iS7-2/4
204
419
208
8.2
7.2
7.7
6.7
SV0037iS7-2/4
204
419
208
8.2
7.2
7.7
6.7
SV0055iS7-2/4
254
461
232
12.8
10.2
12.1
9.5
SV0075iS7-2/4
254
461
232
12.9
10.3
12.2
9.6
SV0110iS7-2/4
313
591
294
25.6
22.8
22.4
19.6
SV0150iS7-2/4
313
591
294
25.9
23.1
22.7
19.9
SV0185iS7-2
343
751
316
38.3
34.2
34.1
29.9
SV0220iS7-2
34
751
316
38.3
34.2
34.1
29.9
SV0185iS7-4
343
751
316
34.9
31
31
27.1
SV0220iS7-4
343
751
316
34.9
31
31
27.1
Note
• The weight specified in the table indicates the total weight of the product without packaging,
which includes the built-in parts, such as the EMC filter and DCR.
• Only 0.75-22 kW products are available in IP 54 Type specifications.
