Displays the inverter’s operation status information. You can
monitor the frequency setting, operating frequency display,
output current, voltage, etc.
Used to configure the functions required to operate the inverter.
These functions are divided into 12 groups based on purpose and
complexity.
Used to define User and Macro groups. These user-definable
groups allow specific functions of the inverter to be grouped and
managed in separate groups.
This mode will not be displayed when navigating through modes if
no User groups or Macro groups have been defined.
Used to monitor the inverter’s fault trip information, including the
previous fault trip history.
When a fault trip occurs during inverter operation, the operation
frequency, output current, and output voltage of the inverter at
the time of the fault can be monitored.
This mode will not be displayed if the inverter is not at fault and a
fault trip history does not exist.
Used to configure the inverter features that are not directly
related to the operation of the inverter. The settings you can
configure in Configuration mode include keypad display language
options, monitor mode environment settings, communication
module display settings, and parameter duplication and
initialization.
5.2.1
Parameter Mode
Includes frequency/acceleration/deceleration time setting,
operation command selection, etc.
Configures basic operation parameters. These parameters include
motor parameters and multi-step frequency parameters.
Configures acceleration or deceleration, patterns, and frequency
limits.
Configures functions related to sensorless and vector control.
Input terminal
function group
Configures input terminal–related features, including digital multi–
functional inputs and analog inputs.
