LSIS SV-IS7 User Manual

Using a Single Phase Power Source
233
Single
Phase
Single-Phase Current Rating (200V/60Hz)*
[kW]
[HP]
Output Amp
Input Amp
HD [A]
ND [A]
HD [A]
ND [A]
5.5kW
7.5
12
16
22.1
28.6
7.5kW
10
16
23
28.6
41.2
11kW
15
24
31
44.3
54.7
15kW
20
31
38
55.9
69.7
18.5kW
25
38
45
70.8
82.9
22kW
30
45
64
85.3
116.1
30kW
40
60
75
121.0
152.0
37kW
50
75
93
154.0
190.0
45kW
60
93
114
191.0
231.0
55kW
75
114
149
233.0
302.0
75kW
100
149
178
305.0
362.0
* The drive ratings in table are valid for 60 Hz input only.
12.3 Input Frequency and Voltage Tolerance
The AC supply voltage must be within the required voltage range of 240/480 VAC +10% to –5%
to maximize motor power production.
The standard product with three-phase voltage input has an allowable range of +10% to –15%.
A stricter input voltage tolerance of +10 to –5% applies when using the drive with a single-
phase supply. The average bus voltage with single-phase input is lower than the equivalent of a
three-phase input. Therefore, the maximum output voltage (motor voltage) will be lower with a
single-phase input.
The minimum input voltage must be no less than 228 VAC for 240 volt models and 456 VAC for
480 V models, to ensure motor voltage production of 207 VAC and 415 VAC, respectively.
If full motor torque must be developed near the base speed (full power) it will be necessary to
maintain a rigid incoming line voltage so that adequate motor voltage can be produced.
Operating a motor at reduced speed (reduced power), or using a motor with a base voltage
that is lower than the incoming AC supply rating (ex. 208 VAC motor with a 240 VAC supply) will
also minimize the effect of voltage deprivation ( 240 VAC Input for 208 V motor, 480 VAC Input
for 400 V motor).
