8.13 Trip Mode (TRP Current (or Last-x))
Trip Mode (TRP Last-x)
No.
LCD Display
Name
Setting Range
Initial Value
00
Trip Name ( x)
Trip type display
-
-
01
Output Freq
Output frequency at trip
-
-
02
Output Current
Output current at trip
-
-
03
Inverter State
Acc/Dec status at trip
-
-
04
DCLink Voltage
DC voltage
-
-
05
Temperature
NTC temperature
-
-
06
DI State
Status of input terminals
-
0000 0000
07
DO State
Status of output terminals
-
000
08
Trip On Time
Trip time since power on
-
0/00/00 00:00
09
Trip Run Time
Trip time since operation start
-
0/00/00 00:00
10
Trip Delete
Delete trip history
0
No
0:No
1
Yes
8.14 Config Mode (CNF)
Config Mode (CNF)
No.
LCD Display
Name
Setting Range
Initial Value
00
Jump Code
Jump code
0-99
1
01
Language Sel
Keypad language selection
0. English
0. English
1. Russian
2. Español
3. Polski
4. Turkish
02
LCD Contrast
LCD contrast adjustment
-
-
10
Inv S/W Ver
Inverter S/W version
-
1.XX
11
KeypadS/W Ver
Keypad S/W version
-
1.XX
12
KPD Title Ver
Keypad title version
-
1.XX
20
Note43)
Anytime Para
Status display
0
Frequency
0: Frequency
21
Monitor Line-1
Monitor mode
display 1
1
Speed
0: Frequency
22
Monitor Line-2
Monitor mode
display 2
2
Output Current
2:Output
Current
23
Monitor Line-3
Monitor mode display 3
3
Output Voltage
3:Output
