Installing the Inverter
42
3.7 Installation Procedures for UL Enclosed Type12
and IP54 Type Products
3.7.1 Disassembling the Keypad Cover and Keypad
1 Loosen the screws that secure the keypad cover and remove the keypad cover.
2 Depress the tab at the top of the keypad and gently lift the keypad from the inverter to
remove it. Be careful not to damage the keypad cable.
