LSIS SV-IS7 User Manual

Table of Functions
166
8.4 Parameter Mode – Control Function Group
(CON)
Control Function Group (PAR  CON)
No.
Communi-
cation
Address
LCD Display
Name
Setting Range
Initial Value
Shift in
Opera-
tion
Control Mode
V
/
F
S
L
V
C
S
L
T
V
C
T
00
-
Jump Code
Jump code
0-99
51
O
O
O
O
O
O
04
0h1404
Carrier Freq
Carrier
frequency
Below 22
kW
0.7 – 15
(kHz)
5.0
O
O
O
O
O
O
30-45 kW
0.7 – 10
(kHz)
5.0
55-75 kW
0.7 – 7 (kHz)
5.0
90-110 kW
0.7 – 6 (kHz)
3.0
132-160 kW
0.7 – 5 (kHz)
3.0
185-220 kW
0.7 – 3 (kHz)
2.0
280-375 kW
0.7 – 2 (kHz)
2.0
05
0h1405
PWM Mode
Switching mode
0
Normal PWM
0:Normal
PWM
X
O
O
O
O
O
1
Low leakage PWM
09
0h1409
PreExTime
Initial excitation
time
0 – 60 (sec)
1.00
X
X
X
O
O
O
10
0h140A
Flux Force
Initial excitation
power supply
100 – 500 (%)
100.0
X
X
X
O
O
O
11
0h140B
Hold Time
Continued
operation
duration
0 – 60 (sec)
Dependent
on control
mode
X
X
X
O
X
X
12
0h140C
ASR P
Gain 1
Speed controller
proportional
gain 1
10 – 500 (%)
50.0
O
X
X
O
X
X
13
0h140D
ASR I
Gain 1
Speed controller
integral gain 1
10 – 9999 (msec)
300
O
X
X
O
X
X
15
0h140F
ASR P
Gain 2
Speed controller
proportional
gain 2
10 – 500 ( %)
50.0
O
X
X
O
X
X
16
0h1410
ASR I
Gain 2
Speed controller
integral gain 2
10 – 9999 (ms)
300
O
X
X
O
X
X
18
0h1412
Gain SW Freq
Gain exchange
frequency
0 – 120 (Hz)
0.00
X
X
X
O
X
X
19
0h1413
Gain Sw
Delay
Gain exchange
time
0 – 100 (sec)
0.10
X
X
X
O
X
X
20
0h1414
SL2 G
View Sel
Sensorless 2nd
gain display
setting
0
No
0:No
O
X
X
X
X
X
1
Yes
21
0h1415
ASR-SL P
Gain1
Sensorless
speed controller
proportional
gain1
0 – 5000 (%)
Dependent
on motor
capacity
O
X
O
X
X
X
22
0h1416
ASR-SL I
Gain1
Sensorless
speed controller
integral gain 1
10 – 9999 (ms)
Dependent
on motor
capacity
O
X
O
X
X
X
23
0h1417
ASR-SL P
Senseless speed
1.0 – 1000.0 (%)
Dependent
O
X
X
X
X
X
