LSIS SV-IS7 User Manual

Table of Functions
Function
Table
165
No.
Communi-
cation
Address
LCD Display
Name
Setting Range
Initial
Value
Shift in
Opera-
tion
Control Mode
V
/
F
S
L
V
C
S
L
T
V
C
T
78
0h134E
RegenAvd
Igain
Regeneration evasion
for press I gain
20 – 30000 (ms)
500 (ms)
O
O
O
O
X
X
79
0h134F
DB Turn On
Lev
DB unit operating
voltage
200 V : 350 – 400 (V)
390 (V)
X
O
O
O
O
O
400 V : 600 – 800 (V)
780 (V)
80
0h1350
Fire Mode
Sel
Select fire mode
0
None
0:None
X
O
O
O
X
X
1
Fire Mode
2
Fire Test
81
Note16)
0h1351
Fire Mode
Freq
Fire mode frequency
0-maximum frequency
(Hz)
60.00
X
O
O
O
X
X
82
0h1352
Fireq Mode
Dir
Fire mode operating
direction
0
Forward
0:Forwar
d
X
O
O
O
X
X
1
Reverse
83
-
Fire Mode
Cnt
Fire mode counter
0-99
0
X
O
O
O
X
X
85
0h1355
U/D Mode
Sel
U/D Mode
0
U/D Normal
0:U/D
Normal
X
O
O
O
X
X
1
U/D Step
2
U/D Step+Norm
86
Note17)
0h1356
U/D Step
Freq
U/D
step frequency
0-maximum frequency
[Hz]
0.00
O
O
O
O
X
X
92
0h135C
SlipGain
Mot-H
slip compensation
offsetting gain H
0~200[%]
50
O
O
X
X
X
X
93
0h135D
SlipGain
Gen-H
slip compensation
regenerative gain H
0~200[%]
50
O
O
X
X
X
X
94
0h135E
SlipGain
Mot-L
slip compensation
offsetting gain L
0~200[%]
50
O
O
X
X
X
X
95
0h135F
SlipGain
Gen-L
slip compensation
regenerative gain L
0~200[%]
50
O
O
X
X
X
X
96
0h1360
Slip Filter
slip compensation
filter
0~10000[msec]
300
O
O
X
X
X
X
97
0h1361
Slip Comp
Freq
slip compensation
frequency
0~60.00[Hz]
5.00
O
O
X
X
X
X
98
0h1362
Slip Gain
Freq
slip compensation
gain switchover
frequency
0~20.00[Hz]
9.00
O
O
X
X
X
X
* The grey cells indicate a hidden code which is only visible when setting a code.
Note 14)
ADV-71 – 72 is displayed only when ADV-70 (Run En Mode) is set as “DI Dependent”.
Note15)
ADV-76 – 78 is displayed only when ADV-75 (RegenAvd Sel) is set as “Yes”.
Note16)
ADV-81 – 83 displayed only when ADV-80 (Fire Mode Sel) is set as “Fire Mode” or “Fire Test”.
Note17)
ADV-86 is displayed when ADV-85 (U/D Mode Sel)is not set to “U/D Normal”.
